FRP 10-seater Toilet

Product Description

FRP 10-SEATER TOILET SP-38

• Toilet Size:- 15ft x 8ft

• Toilet Seat:- India Style Seat

• Structure:- 1" x 1" MS square pipe & angle

• Panelling:- FRP material of 3mm thickness

• Doors:- FRP material of 3mm thickness

• Roof:- FRP material of 3mm thickness

• Wash Basin:- 01 no. for Gents & 01 no. for Ladies

• Water Tank:- Overhead water tank of 800-1000 litres

capacity

• Sludge Tank:- Beneath of 800-1000 litres capacity

• Fitting:- Water filling line at the front of the toilet van;

Sludge drain valve 100mm dia heavy duty butterfly valve

provided at the rear of the unit

• Print Process : Anti Corrosive Polly Urethane paint over

two coat of Epoxy primer, Respective words of “FOR GENTS

“FOR LADIES” & “MOBILE TOILET” Written on both sides,

Water tank with internally painted by Epoxy primer.

Trailer Specification

• Trailer size : 19’ X 10.7’ X 8’

• Chassis Frame : Four wheel chassis with heavy duty made

from ISMC 125 X 65 mm channel.

• Tyre : 4 nos. of tyre with tube flap with size of 616 X 16

• Axles : 2 Nos. of axel with size of 60X60mm M.S.

• Hub : 4 Nos. with material of cast steel
