Frp 8-seater Toilet

Product Description

FRP 8-SEATER TOILET

• Toilet Size:- 15ft x 7ft

• Each compartment size:- 3.5ft x 3.5ft x 6.5ft

• Toilet Seat:- India Style Seat

• Structure:- 1" x 1" MS square pipe & angle

• Panelling:- FRP material of 3mm thickness

• Doors:- FRP material of 3mm thickness

• Roof:- FRP material of 3mm thickness

• Wash Basin:- 01 no.

• Water Tank:- Overhead water tank of 1000 litres capacity

• Sludge Tank:- Beneath of 1000 litres capacity

• Fitting:- Water filling line at the front of the toilet van;

Sludge drain valve 3inch dia heavy duty butterfly valve

provided at the rear of the unit

• Paint Process : Anti Corrosive Polly Urethane paint over

two coat of Epoxy primer.

Trailer Specification

1. Trailer size : 19’ x 7’

2. Chassis Frame : Four wheel chassis with heavy duty

made from ISMC 80mm x 40mm x 3mm channel.

3. Tyre : 04 nos. of tyre with tube flap with size of 616 X 16

4 Axles : 02 No. of axle with size of 50X50mm M.S.

5. Hub : 04 Nos. with material of cast steel

6. Wheel : 04 Nos.\
